TISS9826
Engine Applications
● Caterpillar: G3508 / G3512 / G3516 / G3516B / G3520 / G3520C / G3600 Series
● Cummins: QSV 81G / QSV 91G / QSK 19G / QSK 45G / QSK 60G / QSK 38G / QSK 50G
● Guascor: FG180 / FGLD180 / FG240 / FGLD240 / FGLD360 / FGLD480 / SFGLD480
● Perkins: 4000 Series
● Superior: 1706G2 / 1712G1 / 2400 G Series
● Waukesha: AT27GL Series - 13/16" Rch Heads / P48 / L36 / H24 / F18 / P9390GL - 13/16 Rch Heads/L7044GSI/F3521GL/F2895GL
Target applications
● Industrial stationary engines
● Power generation/CHP
● Fast Power & Resilience
● Natural Gas
● Furnace Gas
● Landfill Gas
● Sewage Gas
● Biogas
Brand reference (Electrode design Ir/Ir)
Beru:
Super Green Spark Plug 18 GZ 4-77 / 18GZ4-77/ 18-GZ-4-77/ 18 GZ 6-77 / 18GZ6-77/ 18-GZ-6-77/18 GZ 20/ 18GZ20/ 18-GZ-20/
18 GZ 6-77-2 / 18GZ6-77-2/ 18-GZ-6-77-2/ 18 GZ 7 / 18GZ7/ 18-GZ-7/RB76N / RB76PP / RB75N / RB75PP
Bosch:
7302 / 7305
Denso:
GI3-1 / GI3-5 / Gi 3-5
Caterpillar:
194-8518 / 224-2700 / 243-4291 / 301-6663
Champion:
RB77CC / RB77N / KB75N / RB75N / RB77WPC / RB77WPCC
Champion Premium:
FB77WPCC / KB77WPCC
Denso:
GI3-3 / GI 3-3
ALTRONIC:
L1863B / L1863IP / L1863DP
Waukesha:
60999Z / 69919D
Cummins:
4098162 / 4010981 / 2866879
STITT:
RL807LL
GATEWAY:
1175112 / 1177512 / 1176112
|
Code: |
TISS9826 |
|
Thread Diameter: |
M18*1.5 |
|
Thread Reach: |
20.5 mm |
|
Hex Size: |
22.2 mm |
|
Gap Size: |
0.25-0.3 mm |
|
Center Electrode: |
Iriduim |
|
Ground Electrode: |
Platinum |
|
Resistance: |
3-9 kΩ |
|
Torque Value: |
45-50 Nm |
|
Service life: |
3000-5000 h |
|
Net weight: |
0.11 kg |
The TISS9826 spark plug is designed for superior performance in industrial engines, providing durability, efficiency, and reliability for a variety of demanding applications. Here are its detailed benefits:
1. High-Quality Platinum Electrodes: Both the centre and ground electrodes are made of Platinum, a material known for its exceptional durability and resistance to wear. This ensures precise and consistent ignition, leading to reliable engine performance and extended service life.
2. Optimized Combustion Efficiency: The 0.3mm gap size is precisely calibrated to deliver efficient spark propagation and robust combustion. This results in improved fuel efficiency, lower emissions, and better overall engine performance.
3. Exceptional Heat Dissipation and Stability: With an 18mm thread diameter and 22.2mm hex size, the TISS9826 is engineered to dissipate heat effectively, preventing overheating and ensuring stability under high-temperature and high-load conditions.
4. Compatibility with a Wide Range of Engines: The TISS9826 spark plug is compatible with gas generators from leading manufacturers, including Caterpillar, Cummins, Guascor, Perkins, Superior, and Waukesha. This broad compatibility makes it a versatile option for industrial and power generation applications.
5. Trusted Cross-Referencing Options: The TISS9826 is a direct replacement for numerous industry-standard spark plugs, such as Bosch 7302, Champion RB77CC, and Caterpillar 194-8518, among others. This ensures ease of integration and reliability across a variety of engine models.
6. Resistance to Electrical Interference: With a resistance value of 3kOhm, the spark plug minimizes electrical noise and interference, enabling reliable ignition performance and seamless operation with modern ignition systems.
7. Durability in Extreme Conditions: The use of Platinum electrodes ensures that the TISS9826 performs effectively even in harsh environments, providing resistance to corrosion and electrode erosion. This makes it ideal for engines operating under high-compression or aggressive conditions.
8. Reduced Maintenance Costs: Thanks to its robust design and high-quality materials, the TISS9826 requires less frequent replacement, resulting in lower maintenance costs and downtime for operators.
9. Engineered for Secure Installation: The precise thread dimensions and design ensure secure installation and proper torque application, enhancing safety and reliability during operation.
10. Environmental Benefits: With efficient combustion and reduced emissions, the TISS9826 supports environmentally conscious operations, contributing to a lower carbon footprint.
In summary, the TISS9826 spark plug is a high-performance solution designed to meet the demands of industrial gas engines. Its durability, compatibility, and efficiency make it a trusted choice for a wide range of applications.
